Home Elevators
Monarch is one of the fastest growing companies in the vertical transportation industry with in house R&D and manufacturing facilities. Safety and reliability form a part of our core values.
With our elegant design and best-in-class functionality, Monarch elevators are perfect blend of our global expertise and Indian design sensibilities. It also underscores our commitment to the ‘Make in India’ initiative.
We have formed a strong ‘technical team’ with years of experience to provide necessary inputs at design stage, sales, installations and after sales service. Our services will be the best in class to support our customer while exceeding their expectations.
Advantages :
- Wisdom:
Using variable frequency drive technology and all-computer controlled technology, makes the elevator control system more flexible and accurate, effcient and reasonable.
- Environmental Protection:
Using the advanced permanent magnet synchronous traction machine, reduce the layout size inside the elevator shaft. There is no machine room and also do not need an additional structural strength of the building, saving the architectural space, greatly reducing the cost of construction.
- Comfort:
Using the permanent magnet synchronous gearless technology brings you a very smooth and comfortable ride.
- Energy Saving:
Low energy consumption, as it saves energy more than 45% than the average elevator. Effcient and eco friendly drive create less noise, reducing power supply capacity, saving the users investment cost.
- Security:
Safety is the most important issue of choosing Monarch’s home elevators, it is in accord with the home lift manufacturing and installation standards and provide you with reliable safety guarantee.
- Delicacy:
Delicate appearance and compact layout arrangement, combined with modern upscale architectural design style, make the buildings, such as villa, more beautiful.
Special Parameters :
- Full collective control
- Car lighting automatic control
- Adjustable door opening & closing time and speed
- Overload protection
- Alarm button
- Electric brake release device
- Emergency lighting
- Landing door emergency unlocking function
- Car voice announcements
- Power failure emergency device
- Electric door lock
- Pit depth 300mm-1350mm
Standard Dimensions
|
| No. of Passangers |
Load (kg) |
Speed (m/s) |
Car Width (CW) |
Car Depth (CD) |
Shaft Width (SW) |
Shaft Depth (SD) |
Car Opening (DW) |
Pit depth |
Min. Headroom height |
| 4 |
272 |
0.3 |
700 |
1100 |
1100 |
1500 |
700 |
300 |
3600 |
| 5 |
340 |
0.3 |
850 |
1100 |
1250 |
1500 |
700/800 |
300 |
3600 |
| 6 |
408 |
0.3 |
1000 |
1100 |
1400 |
1500 |
800/900 |
300 |
3600 |
